OPTICROSS™ 18
Peripheral Imaging Catheter
The OptiCross 18 IVUS catheter delivers confidence to guide complex lesions. The best in class deliverability enables crossing challenging lesions while providing exceptional image quality.
Key Resources
Explore
Product Details
Exceptional Deliverability
- Balloon tip technology to facilitate crossing and deliverability
- Small crossing profile and shaft stiffness transitions for excellent deliverability
- Lubricious coating promotes deliverability
Best in Class Image Quality
- 30 MHz transducer frequency allows for deeper ultrasound penetration than a 40 MHz transducer frequency
- Ability to visualize larger vessel sizes with higher image resolution than a 20 MHz transducer frequency
Ease of Use
- Stronger proximal shaft for great pushability
- Ease of flush for quick prep
- Compatible with iLab™ POLARIS Multi-Modality Guidance System
Clinical Data
Product Specifications
OptiCross™ 18 Peripheral Imaging Catheter |
|
---|---|
Transducer Frequency | 30 MHz |
Order Number |
|
Typical Use | SFA, Popliteal, Tibial, Renal |
Maximum Diameter Penetration | 12 mm |
Prep Location | Proximal |
Catheter Telescoping Length | 15 cm |
Sled Pullback Length | 10 cm |
Distance from Transducer to Tip | 2.0 cm |
Guidewire Lumen Length | 1.6 cm |
Guidewire Compatibility | ≤ 0.018" |
Sheath Compatibility (with max wire) | 6 F |
Guide Catheter Compatibility | 6 F (ID ≥ 0.068") |
Crossing Profile | 3.5 F |
Imaging Window Profile | 2.9 F |
Entry Profile | 1.6 F |
Working Length | 135 cm |
Necessary Equipment
The following are required for use of the OptiCross 18 Peripheral Catheter:
- AVVIGO Guidance System II
- MDU5 PLUSTM Motor Drive Unit
Ordering Information
Product Code | Catalog Number | Material Description | GTIN |
---|---|---|---|
H7493932800180 | 390590018 | OPTICROSS 18 | 08714729904366 |
Reimbursement
Related Technologies
1. Secemsky, E. A., Mosarla, R. C., Rosenfield, K., Kohi, M., Lichtenberg, M., Meissner, M., Varcoe, R., Holden, A., Jaff, M. R., Chalyan, D., Clair, D., Hawkins, B. M., & Parikh, S. A. (2022). Appropriate use of intravascular ultrasound during arterial and venous lower extremity interventions. JACC: Cardiovascular Interventions, 15(15), 1558–1568.https://pubmed.ncbi.nlm.nih.gov/35926922/
