RHYTHMIA HDx™

Mapping System

RHYTHMIA HDx System
Heart Image
RHYTHMIA HDx™ Mapping System
Left atrial activation map image courtesy of Elad Anter, MD, BIDMC.
The combination of a high-resolution mapping catheter, advanced noise-filtering hardware and intelligent software work together to achieve density, resolution and automation.

Boston Scientific Corporation’s RHYTHMIA HDx™ Mapping System sets a new bar in Ultra High-Definition mapping by using three main features: density, resolution and automation. Each is essential in creating Ultra High-Definition maps.

Key Resources

Explore


Experience RHYTHMIA HDx


Ordering Information

UPN Number

UPN Description

M004 RBINSTALL2ROW0

RHYTHMIA System Install Bundle 2 ROW

RHYTHMIA HDx Mapping System Installation Bundle

Installation Bundle - Components List

UPN Number

UPN Description

QTY

M004 RH1020 0

Signal Station 2

1

M004 RALRCBL2 0

RHYTHMIA Patch Cable

1

M044 RH4010 0

RHYTHMIA Workstation PC G2

1

M004 RAPWR2 0

RHYTHMIA Power Supply 2

1

M004 RH1102 0

RHYTHMIA Breakout Box

2

M004 RH1112 0

RHYTHMIA Breakout Box Cable

2
M004 RAMMTIPS22 Male to Male Tip-Jacks 2-2 Pin 2 1

M004 RAGPS0 0

Global IEC Power Strip

1

M004 RAINST001 0

Optical DVI - Duplex Kit

1

M004 RAINST002 0

LC FIBER Coupler - Duplex

1
M004 2001105 0 Cable, Equipotential Grind 1
M004 RARS232MF10 0 DB9 RS232 Serial Cable Strt Thr M-F 10ft 1
M004 RAUSBRS232MM 0 USB to DB9 RS232 Adapter M-M 1
M004 RAINST010 0 RFG Serial Data Tab 2

RHYTHMIA HDx Mapping System - Required Accessories

Localisation System

UPN Number

UPN Description

M004 RH2001 0

Localisation Generator 2

M004 RALGBEDMT 0

Localisation Generator Bed Mount

M004 RA7101 0

Localisation Generator Cable 2

ECG In Configuration

UPN Number

UPN Description

M004 RA5010I0

ECG Cable - Trunk - IEC R2

M004 RA5110I0

ECG Cable - L/C - IEC R2

IC Out Configuration

UPN Number

UPN Description

M004 RH1122 0

RHYTHMIA IC Out Cable 72

M004 RA9000ICAB3 0

Direct Connect Clearsign IC A/B 3m

M004 RA9000ICAB6 0 Direct Connect Clearsign IC A/B 6m
M004 RA9000ICM3 0 Direct Connect Clearsign IC Orion 3m
M004 RA9000ICM6 0 Direct Connect Clearsign IC Orion 6m
M004 RA9100IC3 0 Direct Connect CardioLab IC 3m
M004 RA9100IC6 0 Direct Connect CardioLab IC 6m

IC Out Configuration

UPN Number

UPN Description

M004 RH1122 0

RHYTHMIA IC Out Cable 72

M004 RA9000ICAB3 0

Direct Connect Clearsign IC A/B 3m

M004 RA9000ICAB6 0 Direct Connect Clearsign IC A/B 6m
M004 RA9000ICM3 0 Direct Connect Clearsign IC Orion 3m
M004 RA9000ICM6 0 Direct Connect Clearsign IC Orion 6m
M004 RA9100IC3 0 Direct Connect CardioLab IC 3m
M004 RA9100IC6 0 Direct Connect CardioLab IC 6m

RHYTHMIA HDx Mapping System - Optional Accessories

Cart Configuration

UPN Number

UPN Description

M004 RASSCART 0

RHYTHMIA System Cart

M004 RAWRKCART 0

RHYTHMIA Workstation Cart

M004 RACARTARM 0

RHYTHMIA Cart Monitor Arm

M004 RACARTARMEXT 0 RHYTHMIA Cart Monitor Arm Extender
M004 RH4100 0 RHYTHMIA Workstation Monitor

Optional Accessories

UPN Number

UPN Description

M004 RA6201 0

Connection Box - Maestro G2

M004 Rh1501 0

Foot Switch 2

M004 RALRBEDSTRP 0 Localisation Generator Bed Strap
