OPAL HDx™ Mapping System

OPAL HDx provides integrated mapping for both RF and pulsed field ablation procedures while giving enhanced access to the transformational capabilities of the FARAPULSE™ Pulsed Field Ablation System. Offering a complete range of mapping solutions, OPAL HDx allows you to choose the treatment modality that best meets your case needs.

Boston Scientific welcomes our RHYTHMIA HDx™ customers to the OPAL HDx Mapping System, a full-spectrum mapping experience at the leading edge of PFA.

Request a sales rep
Explore training on EDUCARE

Explore training on EDUCARE

 OPAL HDx Mapping System Brochure

OPAL HDx Mapping System Brochure

Full-spectrum cardiac mapping

The OPAL HDx™ Mapping System enables visualization of the catheter during FARAPULSE™ Pulsed Field Ablation System procedures in the treatment of atrial fibrillation.
The OPAL HDx system also provides ultra-HD cardiac mapping in support of conventional ablation procedures and integration with our portfolio of RF catheters.
The Boston Scientific FARAVIEW™ System shown on a monitor and FARAWAVE™ NAV Pulsed Field Ablation Catheter next to it.

Integrated cardiac mapping for FARAPULSE™ PFA workflows

The FARAVIEW™ Software Module will let operators visualize and confirm pulsed field applications while unlocking workflow simplicity. The FARAVIEW Software Module is available only on the OPAL HDx Mapping System, and fully integrates with the FARAPULSE PFA system using the FARAWAVE™ NAV PFA catheter.
A colourful heart showing cardiac mapping signals.

Conventional mapping

Combining advanced signal-processing hardware, high-volume data-processing algorithms and rapid analysis software with the high-fidelity EGM capture of the INTELLAMAP ORION™ Mapping Catheter, OPAL HDx provides unparalleled HD cardiac mapping in conventional cardiac ablation procedures.

FARAVIEW™ Software Module

A transformative solution for PFA. Learn more about the cardiac mapping solution for FARAPULSE Pulsed Field Ablation System.
The Boston Scientific FARAVIEW™ System shown on a monitor and FARAWAVE™ NAV Pulsed Field Ablation Catheter next to it.


The mapping solution for the FARAPULSE Pulsed Field Ablation System

The FARAVIEW Software Module on the OPAL HDx system gives physicians enhanced ability to visualize pulsed field ablations.
The Boston Scientific FARAPULSE™ NAV Pulsed Field Ablation Catheter.

Single-catheter solution

Map and ablate with a single magnetically tracked PFA catheter. The FARAWAVE NAV Pulsed Field Ablation Catheter is designed to minimize catheter exchanges.
The Boston Scientific FARAPULSE™ NAV Pulsed Field Ablation Catheter mapping a heart.

Dynamic visualization

Visualize pulsed field delivery and fine-tune your ablation strategy by visualizing catheter shape, rotation, and transitions in real-time.
The Boston Scientific FARAPULSE™ NAV Pulsed Field Ablation Catheter mapping a heart.

FIELDTAG™ Technology

Evaluate field volume, see the intersection of field with anatomy, and automated FIELDTAG PFA markers.

Conventional HD mapping and RF capabilities

Evolved from the RHYTHMIA HDx cardiac mapping system, the OPAL HDx mapping toolset captures and annotates high-fidelity EGM signals, providing a more complete understanding of the electrical circuit.
The Boston Scientific INTELLANAV ORION™ Mapping Catheter.

Precise localization of even the most complex arrhythmias

The multi-spline design and small electrodes of the INTELLANAV ORION™ Mapping Catheter support greater EGM signal capture and map resolution. The catheter’s small 0.4 sq mm flat electrodes offer improved near-field signal quality. The catheter provides 180-degree maneuverability and 28 mm range.
A colourful heart showing cardiac mapping signals.

Rapid identification of areas of clinical interest

Continuous mapping employs four Beat Triggers and seven Beat Acceptance Criteria to ensure that only beats from the rhythm of interest are captured. With the system’s LUMIPOINT™ Software Module, physicians can classify EGMs by zone of activation and across cycle length, use rapid late potential reannotation, and pinpoint potential critical isthmuses.
The Boston Scientific INTELLANAV STABLEPOINT™ Mapping Catheter.

Enhanced RF ablation delivery with advanced contact force catheters

Compatible with the OPAL HDx Mapping System, the INTELLANAV STABLEPOINT™ Ablation Catheter combines the power of contact force and local impedance to give you dynamic insights at and below the cardiac tissue surface. Learn more.

Review the full portfolio of compatible ablation catheters.

RHYTHMIA HDx™ has evolved to the OPAL HDx™ Mapping System, the full-spectrum cardiac mapping system at the leading edge of PFA.
