OPTICROSS™ HD, 60MHz Coronary Imaging Catheters

Increase resolution without compromising penetration

play icon
Bifurcation performed by Prof. Dubois
OPTICROSS HD Product image
Identify dissections with the OPTICROSS HD 60 MHz Coronary Imaging Catheters
Identify false lumens with the OPTICROSS HD 60 MHz Coronary Imaging Catheters
Identify thrombus with the OPTICROSS HD 60 MHz Coronary Imaging Catheters
Discover a clinical case of LM involving Bifurcation performed by Prof. Dubois with Opticross™ HD (IVUS) and SYNERGY™
OPTICROSS HD Product image
Identify dissections with the OPTICROSS HD 60 MHz Coronary Imaging Catheters
Identify false lumens with the OPTICROSS HD 60 MHz Coronary Imaging Catheters
Identify thrombus with the OPTICROSS HD 60 MHz Coronary Imaging Catheters

High Definition, Clear Results
Set a new standard for image quality, depth and deliverability with the new OPTICROSS HD 60 MHz Coronary Imaging Catheters.

Key Resources

Explore

Image Comparison

OPTICROSS 40 MHz Imaging Catheter vs. OPTICROSS HD 60 MHz Imaging Catheter
The OPTICROSS HD 60 MHz Imaging Catheter provides increased stent visibility with clearer resolution to confirm adequate stent apposition to vessel wall.
OPTICROSS 40MHz versus OPTICROSS HD 60MHz
OPTICROSS HD 60 MHz Imaging Catheter vs. OCT
OPTICROSS HD 60 MHz Imaging Catheter vs. OCT

Product Overview

OPTICROSS™ HD

Coronary Imaging Catheter

OPTICROSS HD Coronary Imagery Catheter

High-Resolution Imaging

Superior Deliverability

A 60 MHz wideband transducer increases lateral and axial resolution for superior image quality to visualize all three vessel layers, plaque morphology, and improves stent strut visibility for better optimization.

Proven Deliverability

Improved Ease of Use

Available in 5F and 6F, catheters feature a trusted, well-balanced design to ensure best-in-class deliverability.

Proven Deliverability

Improved Ease of Use

Available in 5F and 6F, catheters feature a trusted, well-balanced design to ensure best-in-class deliverability.

Unmatched Versatility

Enhanced Image Quality

Expect exceptional near-field visibility for small vessel imaging as well as penetration depth of 6mm for large vessel assessment.



Product Specifications

OPTICROSS Coronary Imaging Catheters Product Specifications



OPTICROSS HD

OPTICROSS

OPTICROSS 6

Typical Use

Coronary

Coronary

Coronary

Transducer Frequency

60 MHz

40 MHz

40 MHz

Maximum Diameter Penetration

6 mm

6 mm

6 mm

Sheath Compatibility (with max wire)

5F

5F

6F

Guide Catheter Compatibility

5F (ID ≥ 0.058")

5F (ID ≥ 0.058")

6F (ID ≥ 0.064")

Guidewire Lumen Length

16 mm

16 mm

16 mm

Guidewire Compatibility

≤ 0.014"

≤ 0.014"

≤ 0.014"

Entry Profile

0.026"

0.026"

0.017"

Imaging Window Profile

2.6F

2.6F

2.9F

Crossing Profile

3.1F

3.1F

3.1F

Prep Location

Proximal

Proximal

Proximal

Catheter Telescoping Length

150 mm

150 mm

150 mm

Sled Pullback Length

100 mm

100 mm

100 mm

Tip to Transducer Distance

20 mm

20 mm

20 mm

Distal Marker to Transducer

15 mm

15 mm

15 mm

Working Length

135 mm

135 mm

135 mm

Hydrophilic Coating

Bio-SlideTM

Bio-SlideTM

Z-GlideTM



Integration Options


POLARIS Multi-Modality Guidance System
Use a single system to inform treatment decisions for IVUS and coronary physiology with fully integrated and mobile options to fit seamlessly in any facility.


Ordering Information

UPN

Actual Description

Idéal Description

H74939352020 HD IVUS CE
OPTICROSS HD 60MHz (5Fr)
H749518120 OptiCross EMEA - IC
OPTICROSS 40MHz (5Fr)
H7495181260

OptiCross 6 CE

OPTICROSS 40MHz (6Fr)
H749MDU5PLUSBAG0 MD U5 PLUS Sterile Bag
MDU5 PLUS Sterile Bag
H749A70200 F/G ASSY SLED PULLBACK SINGLE
Pullback Sled
H749MDU5PLUS0 MD5 MOTORDRIVE UNIT SCIMED
Motor Drive MDU5 PLUS
H749I50330 MD5 MOTORDRIVE
Motor Drive

OPTICROSS Imaging Catheters Preparation Instructions

OPTICROSS Imaging Catheters Preparation Instructions

Watch to learn how to prepare the OPTICROSS Imaging Catheters step by step.
