COMPARE is the world’s first head-to-head prospective, RCT (1:1) comparing low dose Ranger DCB (2 μg/mm2) to higher dose IN.PACT DCB (3.5 μg/mm2).
Ranger demonstrated similar primary patency1 with half the total drug dose.2

Target Lesion Length = ~126 mm Total Occlusions = ~42% Moderate to Severe Calcium = ~54%
12-MONTH PRIMARY ENDPOINTS | RANGER | IN.PACT | p-value |
---|---|---|---|
Binary Primary Patency | 83.0% (156/188) |
81.5% (141/173) |
Pnon-inferiority<0.01 |
Freedom from major adverse events | 91.0% (182/200) |
92.6% (175/189) |
Pnon-inferiority<0.01 |
Both primary endpoints met. |
TRIAL DETAILS | RANGER (n=207) |
IN.PACT (n=207) |
p-value |
---|---|---|---|
Excipient | TransPax™ citrate ester |
Urea | N/A |
Paclitaxel dose density | 2.0 µg/mm2 | 3.5 µg/mm2 | N/A |
Average total paclitaxel dose per patient in trial | 6,971 µg | 13,035 µg | <0.0001 |
BASELINE CHARACTERISTICS | RANGER (n=207) |
IN.PACT (n=207) |
p-value |
---|---|---|---|
Age (year) | 68.2 | 68.4 | 0.79 |
Female | 38.2% | 36.2% | 0.68 |
Current/Former Smoker | 77.3% | 75.3% | 0.63* |
Total Occlusions | 41% | 43% | 0.62 |
Total Occlusion Length | 131 mm | 113 mm | 0.23 |
Target Lesion Length | 124 mm | 128 mm | 0.65 |
Moderate to Severe Calcification** | 50% | 57% | *** |
Diabetics | 31% | 37% | 0.18 |
* p-value based on entire distribution. Never, Former or Current Smokers ** PACSS Grade 3/4 may be considered similar to moderate/severe calcification *** p-value for entire distribution of PACSS Calcium Grades 0, 1, 2, 3, 4 calcium for RANGER vs IN.PACT. p-value was 0.20. |
12 MONTH KEY RESULTS | RANGER (n=207) |
IN.PACT (n=207) |
p-value |
---|---|---|---|
Mortality: All Cause | 2.5% | 1.6% | 0.73 |
Mortality: Device or procedure related | 0% | 0% | N/A |
CD-TLR | 9.0% | 7.4% | 0.59 |
24 MONTH KEY RESULTS | RANGER (n=207) |
IN.PACT (n=207) |
p-value |
---|---|---|---|
Mortality: All Cause | 3.6% | 1.1% | 0.6 |
Mortality: Device or procedure related | 0% | 0% | N/A |
CD-TLR | 17.3% | 13.0% | 0.3 |
Definitions

Primary safety endpoint — composite of freedom from device and procedure-related death through 30-days and freedom from major target limb amputation and CD-TLR through 12 months post index-procedure.
Primary efficacy endpoint — primary patency at 12 months defined as absence of clinically-driven target lesion revascularisation (CD-TLR) or binary restenosis determined as a peak systolic velocity ratio > 2.4 evaluated by duplex ultrasound core laboratory analysis.
CD-TLR — a reintervention performed for ≥ 50% diameter stenosis (confirmed by angiography) within ± 5 mm proximal and/or distal to the target lesion after documentation of recurrent clinical symptoms of PAD (increase of 1 Rutherford class or more) and/or drop of ABI (≥20% or ≥0.15 when compared to maximum early postprocedural level).
