Hot AXIOS™ Stent and Electrocautery Enhanced Delivery System

About the Hot AXIOS™ Stent

The Hot AXIOS™ Stent and Electrocautery-Enhanced Delivery System is indicated for use to facilitate transgastric or transduodenal endoscopic drainage of a pancreatic pseudocyst or a walled-off necrosis with ≥ 70% fluid content or the biliary tract.

Innovative Technology

The Hot AXIOS™ Stent and Electrocautery Enhanced Delivery System enables therapeutic endoscopists to access a symptomatic pancreatic pseudocyst, wallled-off necrosis or the biliary tract via a transgastric or transduodenal approach and place the Hot AXIOS™ Stent.

The system combines a cautery-enabled access catheter with the therapeutic Hot AXIOS™ Stent for a streamlined, exchange-free procedure.

The Hot AXIOS™ System is used under combined endoscopic and EUS guidance. Its electrocautery-enhanced delivery system is designed to facilitate smooth, efficient access into the target structure.

Over 400 endoscopists across Europe area already performing drainage procedures with LAMS for PFC/WON and have the ability to offer this novel procedure to non-surgical patients with acute cholecystitis who would previously have had to receive a poorly tolerated percutaneous drain.1

About the Hot AXIOS Procedure

The stent is implanted by an endoscopist using a therapeutic EUS scope.

The scope is advanced and the transducer used to identify the target structure on the EUS image. The physician may choose to approach the target either transgastrically or transduodenally depending on the patients anatomy, and position of the target.

Once the target has been identified the Hot AXIOS stent is passed though the working channel of the endoscope and locked into place.

Electrocautery is connected and the tip of the delivery system exposed  by unlocking the catheter and moving slowly forward until visible on the EUS image.

After using EUS to look for potential blood vessels, adjusting position to avoid them if necessary, the diathermy pedal is depressed and the delivery system advanced into the target structure with a smooth, steady action.

The first (distal) flange of the stent is released into the target structure, before being retracted to create apposition with the gastric/duodenal wall.

Finally the second (proximal) flange is deployed to create the anastomosis, and the delivery system is removed.



How is the Hot AXIOS™ implanted?

Video and 3d loading...

The endoscope is inserted and site for AXIOS Stent placement is identified. Using EUS, the stomach and duodenum are surveyed to identify a site that is clear of intervening blood vessel, where the gall bladder is close to the GI tract (within 10mm), and at an angle providing enough diameter to accommodate insertion of the HOT AXIOS Delivery Catheter (catheter should pass 3-4cm into the target structure).

The Hot AXIOS™ stent catheter is unlocked and advanced forward to until the distal tip is visible. The distal ceramic tip contains a diathermy cutting ring which allows for a direct access technique. Electrocautery is applied and the catheter advanced into the gallbladder.

The yellow safety clip is removed and stent lock is unlocked. Under EUS imaging the deployment hub is retracted to the halfway point. A click will be heard as the stent deployment hub automatically locks into place.
Verify with EUS imagining that the distal flange is deployed inside the target structure.

To prepare for proximal flange deployment the catheter is unlocked and the control hub retracted until the distal flange sits gently against the inner wall of the gall bladder.
Maintaining the distal flange of the stent against the inner wall with an oval shape the catheter lock is engaged.

The proximal flange is deployed by unlocking the stent lock and retracting the stent deployment hub until it stops.
The proximal flange is released from the channel of the endoscope by unlocking and advancing the catheter control hub whilst retracting the scope.
Once deployed the delivery system is removed

The final position of the stent is confirmed using EUS.
X-ray can also be used to verify the position although not required.
Confirmation of drainage is confirmed with endoscopic view

ENDO-679803-AA

1 2 3 4 5 6

Decorative Image

Clinical Results

Learn about the efficacy of Hot AXIOS™ for the treatment of cholecystitis in high risk surgical patients

Decorative Image

How Hot AXIOS™ can be used for gallblader drainage?

Learn more with a case study on gallbladder drainage with Hot AXIOS™.
